Hudson Flanges is a midland-based supplier and manufacturer in the UK offering high quality flanges for the supply of multiple industrial applications World-renowned in their precision and expertise aimed at fulfilling the topmost standards of sharing its application such as spacer blinds flanges will be ensured to reach in time to satisfaction of the customers While being precise in classification and distribution, Hudson Flanges offering a guaranteed reliable and cost-cutting solution to projects demanding top-quality flange products.
Spacer blind flanges are generally manufactured with carbon steel, stainless steel, or steel alloy, which has a combination of strength and corrosion resistance. Material typically includes ingredients like iron, chromium, nickel and possibly molybdenum for increased durability. The technical characteristics consist of high tensile strength, superior resistance to fatigue and resistance to high-pressure conditions. The key benefits are ease of fitting high-temperature and pressure resistance and compatibility with different pipes. They create a close seal and gap between the flanges, leading to increased flow and mechanical efficiency.
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
|---|---|
| Spacer Blind Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS SP44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Spacer Blind Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Spacer Blinds Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| Spacer Blind | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| Spacer Blind UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Spacer Blind EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Spacer Blinds Production technique | Forged, Heat treated and machined |
| Spacer Blinds Connect Type / Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Spacer Blind Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Spacer Blinds Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Spacer Blind Origin | Indian / West Europe / Japan / USA / Korean |
| Manufacturer of Spacer Blind | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM A182 F316 Stainless Steel Flanges |
| Spacer Blind Uses & application | Bitumen upgraders. Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids. |
| Spacer Blinds Export to | Ireland, Singapore, Indonesia, Ukraine, Saudi & Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, India, Egypt, Oman, Dubai, Peru, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Hudson Flanges, a leading supplier in Midland, UK, offers an extensive selection of Spacer Blinds Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Spacer blind flanges are generally used to create clearance or clearance between two segments of flanges in piping systems. Spacer blind flanges play an essential role where alignment adjustments have to be done, or for maintaining certain clearances between valves, pipes, and other equipment of the system Spacer blind flanges are normally employed to clear the piping partially removed during maintenance or shutdown condition or become oil -gas-chemical process, Widely used in water purification and other process industries.
| ASME/ANSI B16.5 | Spacer Blind |
| PRESSURE CLASS | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc. |
| DIN EN 1092-1 Face Dimensions | PN 2.5, PN 6, PN 10, PN 16, PN 25, PN 40, PN 63, PN 100, PN 160, PN 250, PN 320, PN 400 |
| BS 4504 SEC 3.1, BS 4504[PART 1], BS 1560 BOSS | Spacer Blind |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Yes, we offer custom sizes for Spacer Blinds Flanges to meet specific project needs. Our team at Hudson Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@hudsonflanges.co.uk.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
